ONYX Series Inverters · Up to 200% Oversizing

ONYX UL 10KW

Single-phase IP66 hybrid solar inverter with 3 MPPTs and 16 kW PV input.

Rated Output: 10,000 W
Max AC Output: 11,000 W
Max PV Input Power: 16,000 W
MPPT Voltage Range: 70–540 V
MPPT / Max Input Current: 3 / 30 A + 22 A + 22 A

Enquire Now

Download

Overview

Maximize PV Input Power

Single-phase IP66 hybrid solar inverter with 3 MPPTs and 16 kW PV input.

IP66 Protection
200% Oversizing
Seamless Backup
Stackable up to 9 Units

Single-Phase IP66 Hybrid Solar Inverter

ONYX UL 10KW

Up to 200% Oversizing

IP66 Protection

IP66 ingress protection

16KW

Max. PV Input Power

200%

Oversizing

Up to 200% oversizing allowed with 3 MPPTs

Seamless

Backup

Seamless backup transition under 10 ms

At a glance

Up to 200% PV oversizing with 3 MPPTs
30 A PV input current for high-power modules
Stackable up to 9 units
Generator connection for whole-home and office backup

From the official datasheet

ONYX UL 10KW features

Up to 200% PV oversizing with 3 MPPTs
30 A PV input current for high-power modules
Stackable up to 9 units
Generator connection for whole-home and office backup
Supports AC-coupled solar input
Four application modes
Continuous 110% of nominal AC power, maximum 11 kW AC output
Seamless backup transition under 10 ms
Remote configuration and upgrade
Bluetooth + app + LED + LCD
5 years unlimited inverter parts warranty, lifetime free service warranty
IEC 62109-1/2 safety certification

Stackable up to 9 Units

Generator connection for whole-home and office backup

Remote Configuration

Remote configuration and upgrade

5 Years Warranty

Unlimited inverter parts warranty

Technical data

Key specifications

Rated Output: 10,000 W
Max AC Output: 11,000 W
Max PV Input Power: 16,000 W
MPPT Voltage Range: 70–540 V
MPPT / Max Input Current: 3 / 30 A + 22 A + 22 A
Max DC Voltage: 600 V
Max Efficiency: 98.0%
Battery: 48 V (40–64 V), lithium-ion / lead-acid
Max Charge / Discharge Current: 210 A / 210 A
Parallel: Up to 9 units
Protection: IP66
Dimensions: 420 × 800 × 240 mm
Weight: 35 kg
Warranty: 5 years

Product highlights

Features from the datasheet

Up to 200% PV oversizing with 3 MPPTs
30 A PV input current for high-power modules
Stackable up to 9 units
Generator connection for whole-home and office backup
Supports AC-coupled solar input
Four application modes
Continuous 110% of nominal AC power, maximum 11 kW AC output
Seamless backup transition under 10 ms
Remote configuration and upgrade
Bluetooth + app + LED + LCD
5 years unlimited inverter parts warranty, lifetime free service warranty
IEC 62109-1/2 safety certification

Documentation

Datasheet preview

Technical documentation for ONYX UL 10KW.

Download

ONYX UL 10KW DatasheetOpen in new tab

Common questions

ONYX UL 10KW FAQs

Straight answers from official SolarMax product data.

What is the SolarMax ONYX UL 10KW?

The SolarMax ONYX UL 10KW is a solar inverter in the ONYX Series Inverters. Single-phase IP66 hybrid solar inverter with 3 MPPTs and 16 kW PV input. Key labels include 10 kW, Hybrid, Single Phase, IP66.

What are the key specifications of the ONYX UL 10KW?

Official SolarMax specifications for the ONYX UL 10KW include Rated Output: 10,000 W; Max AC Output: 11,000 W; Max PV Input Power: 16,000 W; MPPT Voltage Range: 70–540 V. Full technical data is published on the product page and datasheet.

Where can I download the ONYX UL 10KW datasheet?

Download the official ONYX UL 10KW datasheet (PDF, 1.2 MB) from https://solarmax.pk/products/onyx-ul-10kw or the SolarMax downloads page at https://solarmax.pk/downloads.

How do I enquire about the ONYX UL 10KW in Pakistan?

Contact SolarMax sales at 0300-1110888 or info@solarmax.pk, or use the product enquiry form on https://solarmax.pk/products/onyx-ul-10kw. Customer care is available at 0317-1113749.

What features does the ONYX UL 10KW include?

Highlighted features of the SolarMax ONYX UL 10KW include Up to 200% PV oversizing with 3 MPPTs; 30 A PV input current for high-power modules; Stackable up to 9 units.
